VM1000 Series

‐121‐

Terminal Control of Digital Input:
The address of
command word
The content of command
2001
BIT0~BIT1： reserved
BIT2：RELAY1 output control
BIT3：RELAY2 output control
BIT4：FMR output control
BIT5：VDO
BIT6~BIT9： reserved
Table 6-10 Digital Output Control
A01 Analog Output Control （writing only）:
Command address Command content
2002 0 ～ 7FFF indicates 0％～ 100％
Table 6-11 A01 Analog Output Control
A02 Analog output Control （writing only）:
Command address Command content
2003 0 ～ 7FFF indicates 0％～ 100％
Table 6-12 A02 Analog output Control
Pulse Output Control （writing only）:
command address command content
2004 0 ～ 7FFF indicates 0％～ 100％
Table 6-13 Pulse Output Control
