SAJ VM1000 User Manual

VM1000 Series

‐144‐

Uncoil and Coil ----20% to 30%
Centrifuge ------- 50% to 60%
Accidental braking load 5%
Generally adopt 10%

Model NO.
Recommended
Power of Brake
Resistor
Recommended
Resistance of Brake
Resistor
Brake
Unit
VM1000-4T011GB 800W ≥43Ω
standard
built-in
VM1000-4T015GB 1000W ≥32Ω
standard
built-in
VM1000-4T18R5G 1300W ≥25Ω
standard
built-in
VM1000-4T022G 1500W ≥22Ω
standard
built-in
VM1000-4T030G 2500W ≥16Ω external
VM1000-4T037G 4kW ≥12.6Ω external
VM1000-4T045G 4.5kW ≥9.4Ω external
VM1000-4T055G 5.5kW ≥9.4Ω external
VM1000-4T075G 7.5kW ≥6.3Ω external
VM1000-4T090G 4.5kW×2 ≥9.4Ω×2 external
VM1000-4T110G 5.5kW×2 ≥9.4Ω×2 external
Table A-2 Configuration Advice of Braking Components

Note：×2 indicates two brake units with brake resistors are used in parallel，×3 and
other number can be concluded by analogy.

