VM1000 Series
‐29‐
2.2.2 Electrical Safety Precautions
When installing, operating or maintaining VFD and other relative equipment, it
needs to take measures to prevent static electricity and electricity shock .Please refer
to precautions in this manual.
2.2.3 Product Electrical Components
The electrical components are as shown on the picture below
Control terminals
Signal ground
Cable inlet
Operation keyboard
Control board
External keypad socket
Main circuit terminals
& Ground terminals
Figure 2-7 Electrical Components
