VM1000 Series
‐39‐
DI6
High-speed pulse
input
Except for DI1~DI5, it can also work as
High-speed pulse input
Max input frequency：100kHz
analog output
AO1-GND analog output 1 A01 is decided by J5 jumper on the control
board, A02 is voltage input
output voltage：0V ～ 10V
output current：0mA ～ 20mA
AO2-GND analog output 2
Digital output FM-CME
Digital output 1/
High-speed pulse
output
Optical coupling isolation, dual polarity
open collector output
Output voltage range: 0–24 V
Output current range: 0–50 mA
Note that CME and COM are internally
insulated, but they are shorted by jumper
externally. In this case DO1 is driven by +24
V by default. If you want to drive DO1 by
external power supply, remove the jumper.
Relay output
T1/A-T1/B
Normally closed
terminal
Contact driving capacity：
AC250V，3A，COS
ø=0.4。
DC 30V，1A
T1/A-T1/C
Normally open
terminal
T2/A-T2/B
Normally open
terminal
Communicati
on terminal
and socket
RS+ RS485 differential signal+
RS- RS485 differential signal-
RJ45 socket External LCD keyboard interface
Table 2-5 Control Terminal and Function
