6. Unpacking Workspace
Dimensions and weight of the packed instrument are indicated below. Check in advance if there is
enough space for safety transportation, unpacking and installation of the instrument.
Dimensions and weight of packed instrument
Dimensions and weight of unpacked instrument
Width: approx. 1,500mm
Height: approx. 930mm
Depth: approx. 900mm
Weight: approx. 210kg
Width: approx. 1,250mm
(excluding the display)
Height: approx. 630mm
Depth: approx. 713mm
Weight: approx. 150kg
