40
4. Insert the power plug of each module into an
electrical outlet with grounding terminals.
Power supply system meeting the following
conditions is needed to connect the power
plugs:
Voltage: 100VAC 115VAC 230VAC
Capacity: EM 15 A or higher 15 A or higher 10 A or higher
CM 15 A or higher 15 A or higher 10 A or higher
CAUTIONS:
• Connect the instrument power cord directly to an electrical
outlet instead of extending it using a different cord, etc.
If the power cord is extended and connected, the supply
voltage may drop and each module may stop working. This is
especially true with the Cryo Module.
• Do not connect/remove the power plug with a wet hand.
Failure to observe the instruction may result in electric shock.
When connecting/removing the power plug, do so by holding
the plug. Connecting/removing the power plug by holding
parts other than the plug may cause fire or electric shock.
• Connect the power plug to a dedicated power outlet with
grounding terminals. If the power plug is not grounded
through proper grounding terminals, electric shock may
result.
5. Determine the position of the instrument. (The rear and sides of the
instrument may be in contact with walls, etc.)
NOTE:
Connect the optional foot pedal, if available. (Refer to 3.3.3 Foot
Pedal)
6. By trainned staff, an offset value for temperature compensation, which is
labeled on the backside of the Cryo Module, is entered in the Embbeding
Module.
CAUTION
To Next Page
