EB 8331-4 EN 91
Decommissioning and disassembly
17.2.6 Communication level
Code Parameters Display/select (select ESC to cancel) Section
Serial interface
A51 Communication ENAB (enabled)
DISA (disabled)
Interface module
A61 Communication ENAB (enabled)
DISA (disabled)
A62 Interface module 485 (RS-485)
USB (USB)
ETH (Ethernet)
NONE (none)
A63 Protocol AUTO (automatic: SSP, Modbus)
MODX (Modbus, adjustable)
Modbus interface module
A64 Station address 1 to 247
A65 Baud rate (in Baud) 1200
2400
4800
9600
192 (19200)
384 (38400)
A66 Stop bits and parity 1SNP (1 stop bit, no parity)
1SEP (1 stop bit, even parity)
1SOP (1 stop bit, odd parity)
2SNP (2 stop bits, no parity)
A67 Bus failure monitoring in min (timeout) 0 to 99
A00 Exit level > ESC
