Code Parameters Display/select (select ESC to cancel) Section

EEPROM error (can only be seen when error exists)

E11 Error: No basic setting NTRV 15

E12 Error: No conguration NCO 15

E13 Error: No calibration NCAL 15

E14 Error: No potentiometer calibration NPOT 15

E15 Error: No transit time NRUN 15

17.2.2 Congurationlevel

Code

Parameters Setting range (select ESC to cancel) WE Section Customer

data

Input signal

c01 Source mA (current signal)

V (voltage signal)

C (Pt-1000)

VIA (via interface)

mA 9.2

c02 Lower range value 0.0 to 15.0 mA 4.0mA 9.2

0.0 to 7.5V 2.0V

c03 Upper range value 5.0 to 20.0 mA 20.0mA 9.2

2.5 to 10.0V 10.0V

c04 Logic 0: Inverted; 1: Not inverted 1

Position feedback signal

c05 Unit mA (current signal)

V (voltage signal)

mA 9.5

c06 Lower range value 0.0 to 15.0 mA 4.0mA 9.5

0 to 7.5 V

c07 Upper range value 5.0 to 20.0 mA 20.0mA 9.5

2.5 to 10.0V

Binary input

c11 Function NONE (inactive)

PRIO (priority position)

NEXT (next entry in information level)

LAMP (backlight activated)

MEND (exit manual level for travel adjust-

ment)

NONE 9.6
