Samson 3730 Series Operating Instructions

100 EB 8389-1S EN
Appendix
Code
no.
Parameter – Readings/
values [default setting]
Description
Note: Codes with marked with an asterisk (*) must be enabled with Code3 prior to conguration.
49* E7* Max. test duration
30 to 25000s, [90 s],
ESC
Test canceled when max. test duration is reached.
E8
Unassigned
E9* Reset 'PST parame-
ters'
Resets partial stroke test parameters.
F Partial stroke test (PST) information · Read only
F0 No test available
F1
Unassigned
F2 x cancelation The test was canceled.
The valve position fell below the x monitoring value (Code49 -
E1).
F3 Δp_out cancelation The test was canceled.
The signal pressure change Δp_out exceeded or fell below the ref-
erence value.
F4 Tolerance band ex-
ceeded
The valve position deviation exceeds the PST tolerance band
(Code49 - E6).
F5 Max. test duration ex-
ceeded
The test was canceled.
The Max. test duration (Code49 - E7) was reached.
F6 Test canceled manual-
ly
F7 Measured data mem-
ory full
The Sampling time (Code49 - d9) is too low. After recording 100
measured values per variable, logging is stopped, but the test con-
tinues until it is completed.
F8 Cancel internal sole-
noid valve/forced
venting
The test was canceled.
The internal solenoid valve has been energized/the forced venting
has been activated.
Appendix
