Page #18 background imageLoading...
Page #18 background image
18 EB 8389-1S EN
Monitoring
2.
Device settings > Alarm settings
Fault alarm at condensed state 'Function
check' (Code 32): Yes
3. Error message in case of 'Maintenance re-
quired' and 'Out of specication' con-
densed states (Code 33): Yes
2.2 Logging
The last 30 generated messages are saved in
the positioner with a time-stamp (logged by
the operating hours counter) and with details
on how long the message exists.
You can view these messages in TROVIS-
VIEW4 in the Diagnostics folder (> Monitor-
ing > Logging).
Logging starts automatically 15 minutes after
initialization. It does not need to be activated
by the user.
Messages are logged when:
Their status classication is not 'No mes-
sage'.
Their recording in the logging is activat-
ed.
The 'Internal solenoid valve/forced vent-
ing/supply pressure' message is only ad-
ditionally logged when the time entered
in 'Min. interval for new logging of inter-
nal solenoid valve' has elapsed between
the generation of two 'Internal solenoid
valve/forced venting/supply pressure'
messages.
Note:
Logging can only be deactivated when
the associated status classication is
set to 'No message'.
Device settings > Alarm settings > Status
classication > Logging
Supply pressure: [Yes], No
Change in friction: [Yes], No
Seat leakage: [Yes], No
Packing leakage: [Yes], No
Pneumatic leakage: [Yes], No
Defective actuator springs: [Yes], No
Manipulated variable range limitation: [Yes],
No
Course of end position: [Yes], No
Positioner-valve linkage: [Yes], No
Manipulated variable range: [Yes], No
Change in manipulated variable range: [Yes],
No
Partial stroke test (PST) [Yes], No
Full stroke test (FST): [Yes], No
On/off valve: [Yes], No
Code 50-58, 61, 63, 76, 81: [Yes], No
Binary input: [Yes], No
Data logger: [Yes], No
Internal solenoid valve/forced venting/supply
pressure: [Yes], No
Min. interval for new logging of internal
solenoid valve: 0 to 5000 s, [300 s]
