17.4 Resetting parameters
Parameters
Reset Code 36
Diag Std DS
Start-up
Type of application (Code 49 - h0) YES YES YES
Reading direction (Code 2) NO YES YES
Initialization mode (Code 6) NO YES YES
Initialization including valve signature (Code 48 - h0) NO YES YES
Pin position (Code 4) NO YES YES
Enter nominal range NO YES YES
Pressure limit (Code 16) NO YES YES
Actuator motion NO NO YES
Principle of operation (Code 48 - d11) NO NO YES
Stem seal NO NO* YES
* Max. cycle count is set to 1000000
Start-up > Fail-safe action
Air supply failure NO NO YES
Power supply failure of positioner NO NO YES
Power supply failure of external solenoid valve NO NO YES
Emergency mode NO NO NO
Start-up > Control parameters
Proportional-action coefcient Kp level (Code 17) NO NO NO
Derivative-action time Tv level (Code 18) NO NO NO
Start-up > Substitute calibration
Initialization mode (Code 6) NO YES YES
Activate upper limit for travel/angle (Code 11) NO YES YES
Direction of action (Code 7) NO YES YES
Proportional-action coefcient Kp level (Code 17) NO NO NO
Derivative-action time Tv level (Code 18) NO NO NO
Substitute calibration optimization NO YES YES
