Samson 3730 Series Operating Instructions

90 EB 8389-1S EN
SIL operator test
NOTICE
The SIL operator test causes the valve
to automatically move. It must only be
started when the plant allows it.
Dening parameters
1. Set Type of application to Control valve.
2. Apply an external set point:
4.0 to 4.5 mA for 3.8 mA emergency
shutdown
4.8 to 5.5 mA for 4.4 mA emergency
shutdown
3. Start SIL operator test.
S001 to S030 appear on the positioner
display one after the other.
1.
Start-up
− Type of application (Code 49 - h0): Control
valve
3.
Diagnostics > Service/maintenance > SIL
operator test
− Start SIL operator test
14.1 Analysis and monitoring
SIL operator test completed successfully
OK appears on the positioner display.
SIL operator test not completed
Possible error code E001 to E030 appears
on the positioner display. The positioner
generates the permanent error code 86 (Fail-
ure - this status classication cannot be
changed).
The emergency shutdown function of the po-
sitioner is no longer guaranteed. The posi-
tioner needs to be returned immediately to
SAMSON.
Diagnostics > Service/maintenance > SIL
operator test
− SIL test:
,
