9. Velocity of air flow & temperature distribution
ΙΙΙ
70
(2) AVMCH105 ✻
1) Velocity of air flow
2) Heating temperature distribution
◆
The standard ceiling height is 8ft. and those values are tested at the standard height.
NN
NN
oo
oo
tt
tt
ee
ee
1.5ft/s
3ft/s
4.5ft/s
6ft/s
3’
4.5’
1.5’
0 1.5’ 3’ 4.5’ 6’ 7.5’ 9’ 10.5’ 12’ 13.5’ 15’
95 F
90 F
84 F
79 F
3’
4.5’
1.5’
0 1.5’ 3’ 4.5’ 6’ 7.5’ 9’ 10.5’ 12’ 13.5’ 15’
Ceiling
Floor
Ceiling
Floor
