2. Receiver & display unit (For Duct)
ΙΙ
5
2-1. Concealed type
(1) Cooling only
(2) Heat pump
Filter sign indicator
Fan indicator
Timer indicator
Remote control sensor
On/Off button
Filter sign indicator
Fan indicator
Timer indicator
Remote control sensor
On/Off button(Blue) & Removing frost
indicator(Red)
◆ The shape of receiver & display unit for cooling model is same with heat pump’s. But their function
and color of indicators are different each other.
◆ This receiver & display unit should be applied to duct type air conditioners when using the wireless
remote controller, and the receiver & display unit wire kit must be purchased together.
