1. Remote controller
ΙΙ
4
1-3. Centralized controller
1-4. Function controller
Operating lamp
All On button
All Off button
On/off indicators
Individual On/Off button
Index
Mode selection button
Indoor unit selection buttons
Test button
Filter reset button
Temperature adjustment
buttons
✻
2)
On/Off button
Fan speed adjustment button
Air flow direction adjustment button
✻
1)
Operating mode
✻ 1) Duct type air conditioner does not have function of adjusting air flow direction.
Therefore, the function is not operated even if you press .
✻ 2) Temperature display is
O
C or
O
F.
