Samsung Electronics DVM Series - Outdoor Unit

ΙΙ . Control System
5. Assigning address
ΙΙ
24
5-2. Outdoor unit
You should display that how many indoor units are connected to the outdoor unit.
Refer to the table below, then turn the arrow to appropriate position.
Rotary switch
Outdoor unit PCB
1
2
3
4
5
6
7
8
One
Two
Three
Four
Five
Six
Seven
Eight
9
A
B
C
D
E
F
-
Nine
Ten
Eleven
Twelve
Thirteen
Fourteen
Fifteen
-
Switch No.
Number of indoor
unit(s)
Switch No.
Number of indoor
unit(s)
