8. Piping and refnet joint selection
39
Λ
Outdoor unit
8-1. Examples of using only Refnet joint (during eight rooms installation)
8-2. Examples of using both Refnet joint and distributor kit
(during eight rooms installation)
Outdoor unit
Distributor kit
