Samsung Electronics DVM Series - Duct Type (Low Silhouette)

ΙΙΙ
31
No. Name Description
1
2
Liquid pipe connection
Gas pipe connection
ø9.52(3/8”) Flare
ø15.88(5/8”) Flare
5-3. Duct type (Low silhouette)
Unit : mm/inch
◆ If you want to install optional parts, refer to an appropriate installation manual.
