Samsung Electronics DVM Series - 3 Interface Module

3. Interface module
ΙΙ
7
Indoor unit address display
Group address display
To centralized controller /
S-Net converter
Interface module address setting
(Each Interface module has its
own address)
From F1, F2 terminal
in the outdoor unit
CN01
F1 F2
R2 R1
To outdoor unit PCB
(DC 12V)
