Ι . Overview
2. DVM line-up
Name Model ExampleExplanation
Electronic
expansion valve kit
(Built-in type)
Electronic
expansion valve kit
(Distributor kit
type)
Discharge duct
Refnet kit
Drain pump
MEV : Optional electronic expansion valve
① : Electronic expansion valve model(2 digits)
② : Manufacturer
③ : Version
④ : Area
MXD : Optional distributor kit
① : Max diameter(2 digits)
② : Kinds(marked as K2 for two kinds)
③ : Minimum diameter
(Marked as 00 only for use of one kind and
marked with minimum diameter for use of two
kinds)
④ : Kinds(marked as K2 for two kinds)
⑤ : Version
⑥ : Area
MDF : Optional distributor duct flange
① : Hole size(ø, cm, 2 digits)
② : Version
③ : Area
MXJ : Optional refnet(Y-joint) kit
① : Inlet pipe diameter(2 digits)
② : Outlet pipe diameter(2 digits)
③ : Version
④ : Area
MDP : Optional drain pump
① : Discharge pressure(cm, 3 digits), 75cm › 075
② : Manufacturer
③ : Version
④ : Area
MEV
① ② ③ ④
MXD ① ② ③ ④ ⑤ ⑥
MDF ① ② ③
MXJ ① ② ③ ④
MDP ① ② ③ ④
• MEV-14SAU
• MEV-18SAU
• MEV-24SAU
1Way cassette
• MXD-14K300AU
(1/4” 3)
• MXD-14K218AU
(1/4” 2, 1/8” 1)
1Way cassette
Wall-mounted type
• MDF-45AU
(Upward type)
• MDF-46AU
(Onward type)
• MXJ-0906AU(Liquid)
MXJ-2212AU(Gas)
• MXJ-1206AU(Liquid)
MXJ-3112AU(Gas)
• MDP-075SAU
(Low silhouette)
• MDP-075SBU(Built-in)
• MDP-H075SAU(HSP)
(3) Options
