ΙΙΙ . Indoor unit
5. Dimension
ΙΙΙ
38
◆ Heat pump
Remote control sensor
Timer indicator
On/off indicator
Remote control sensor
Timer indicator
On/off(Green) & Defrost
cycle(Red) indicator
(2) Display unit
1) 1-Way cassette type
◆ Cooling only
◆ Both cooling only models and heat pump models use the same panel.
However, the function of LED is different with each other.
NN
NN
oo
oo
tt
tt
ee
ee
Fan indicator
Filter clean indicator
Fan indicator
Filter clean indicator
