Chapter 2. Device setup
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
12 0xC1 0xC2 0xC3 0xC4 0xC5 0xC6 0xC7 0xC8 N/A N/A N/A N/A N/A N/A N/A
13 0xD1 0xD2 0xD3 0xD4 0xD5 0xD6 0xD7 N/A N/A N/A N/A N/A N/A N/A N/A
14 0xE1 0xE2 0xE3 0xE4 0xE5 0xE6 0xE7 N/A N/A N/A N/A N/A N/A N/A N/A
15 0xF1 0xF2 0xF3 0xF4 0xF5 0xF6 N/A N/A N/A N/A N/A N/A N/A N/A N/A
• 
10x10 Video Wall Model : (1 ~ 100)
Set Number Data
1 0x01
2 0x02
... ...
99 0x63
100 0x64
Ack
Header Command ID Data
length
Ack /
Nak
r-CMD Val1 Val2 Checksum
0xAA 0xFF 3 ‘A’ 0x89 Wall_
Div
Wall_
SNo
Nak
Header Command ID Data
length
Ack /
Nak
r-CMD Val1 Checksum
0xAA 0xFF 3 ‘N’ 0x89 “ERR”
“ERR” : A code showing what error has occurred.
