83
Chapter 7. Appendix
Appendix
Specications
General
Model Name PM32F-BC PM55F-BC
Panel Size 32 CLASS (31.5 inches / 80.1 cm) 55 CLASS (54.6 inches / 138.7 cm)
Display area 27.5 inches (H) x 15.5 inches (V)
698.4 mm (H) x 392.85 mm (V)
47.7 inches (H) x 26.8 inches (V)
1209.6 mm (H) x 680.4 mm (V)
Audio Output 10 W + 10 W 10 W + 10 W
Power Supply AC 100 to 240 VAC (+/- 10%), 60 / 50 Hz ± 3 Hz
Refer to the label at the back of the product as the standard voltage can vary in different countries.
Environmental
considerations
Operating Temperature : 32 °F – 104 °F (0 °C – 40 °C)
Humidity : 10% – 80%, non-condensing
CAUTION
For installing the housing, keep the internal temperature at 104 °F or below.
Storage Temperature : -4 °F – 113 °F (-20 °C – 45 °C)
Humidity : 5% – 95%, non-condensing
To Next Page
