67
Chapter 5. Menu
Manual Network Setup (Wireless)
Ofces may use static IP addresses.
If this is the case, ask the network administrator for the IP address, subnet mask,
gateway and DNS server address. Enter these values manually.
Getting the Network Connection Values
To view the Network connection values on most Windows computers, follow these
steps.
1 Right click the Network icon on the bottom right of the screen.
2 In the pop-up menu that appears, click Status.
3 On the dialog that appears, click the Support tab.
4 On the Support Tab, click the Details button. The Network connection values are
displayed.
How to set up manually
1 Press the
MENU
button on the remote control.
2 Select Network - Open Network Settings.
3 Select Wireless.
‒ The network function searches for available wireless networks. When done, it
displays a list of the available networks.
4 Select Stop. The verication process stops.
5 Select Add Network.
6 Enter the SSID of the network and select Done.
7 Select the Security type and select OK. If you select Open, move to step 10.
8 If the router has security, enter the password. (Security key or PIN)
9 When done, use the button to move the cursor to Done, and then press . The
network test screen appears and then the verication process starts.
10 When the connection has been veried, select OK.
WPS(PBC)
How to set up using WPS(PBC)
If your router has a WPS(PBC) button, follow these steps.
1 Press the
MENU
button on the remote control.
2 Select Network - Open Network Settings.
3 Select Wireless.
‒ The network function searches for available wireless networks. When done, it
displays a list of the available networks.
4 Select Stop. The verication process stops.
5 Select Use WPS and press .
6 Press the WPS(PBC) button on your router within 2 minutes. Your product
automatically acquires all the network setting values it needs and connects to your
network.
7 The network connection screen appears, and network setup is done.
