Chapter 7. Appendix

Standard signal mode table

This product can be set to only one resolution for each screen size to obtain the optimum picture quality due to the nature of the panel. Using a resolution other than the specied

resolution may degrade the picture quality. To avoid this, it is recommended that you select the optimum resolution specied for your product.

Check the frequency when you exchange a CDT product (connected to a PC) for an LCD product. If the LCD product does not support 85Hz, change the vertical frequency to 60Hz

using the CDT product before you exchange it with the LCD product.

Model Name PM32F-BC / PM55F-BC

Synchronization Horizontal frequency 30 - 80 kHz

Vertical frequency 60 - 75 Hz

Resolution Optimum resolution 1920 x 1080 @ 60 Hz

Maximum resolution 1920 x 1080 @ 60 Hz

• Horizontal frequency

The time required to scan a single line from the left to the right side of the screen is called a horizontal cycle. The reciprocal number of a horizontal cycle is called horizontal

frequency. Horizontal frequency is measured in kHz.

• Vertical frequency

The product displays a single image multiple times per second (like a uorescent light) to display what the viewer sees. The rate of a single image being displayed repeatedly

per second is called vertical frequency or refresh rate. Vertical frequency is measured in Hz.

The screen will automatically be adjusted if a signal that belongs to the following standard signal modes is transmitted from your PC. If the signal transmitted from the PC does

not belong to the standard signal modes, the screen may be blank with the power LED on. In such a case, change the settings according to the following table by referring to the

graphics card user manual.
