4th Edition of TEMI880 IM : Jan. 29. 2007 Page 69 / 119
No. Contents Description Additional Description
○
1
INNER
SIGNAL
Set relay number for the inner
signal output.
▶ See 2.12.3 ON/OFF Signal and Inner
Signal Setting Screen
○
2
TIME SIGNAL
Set relay number for the time
signal output.
▶ See 2.10.4 Time Signal Setting Screen
○
3
ALARM
SIGNAL
Set relay number for the alarm
signal output.
▶ See 2.12.6 Alarm and DI Error Name
Setting Screen
○
4
ON/OFF
SIGNAL
Set relay number for the ON/OFF
signal output.
▶ See 2.12.3 ON/OFF Signal and Inner
Signal Setting Screen
▶ Relay is “ON” after setting time.
☞ Setting time is applied one time.
○
5
TEMP RUN
SIGNAL
Set relay number for the temperature
running signal output.
▶ It occurs that control temperature at
Fix running or Program running.
▶ Relay is “ON” after setting time.
○
6
HUMI RUN
SIGNAL
Set relay number for the humidity
running signal output.
▶ It occurs that control humidity at
Fix running or Program running.
▶ Relay is “ON” after setting time.
○
7
TEMP UP
SIGNAL
Set relay number for the temperature
Up signal output.
○
9
TEMP DOWN
SIGNAL
Set relay number for the temperature
Down signal output.
▶ FIX RUN
→ Setting range : EUS 0% ~ EUS 10%
▶ PROG RUN
→ Relay is “ON” during TSP minus
setting temperature.
→ Setting range is (EUS 0% ~ EUS 10%)
☞ Status lamp of the running screen and
relay is operated at the same time.
○
8
TEMP SOAK
SIGNAL
Set relay number for the temperature
Soak signal output.
▶ When Fix running, status lamp of the
running screen is display but relay
output isn’t occurred.
▶ When Program running, status lamp
of the running screen and relay is
“ON” during Soak time minus setting
time.
○
10
HUMI UP
SIGNAL
Set relay number for the humidity
Up signal output.
○
12
HUMI DOWN
SIGNAL
Set relay number for the humidity
Down signal output.
▶ FIX RUN
→ Setting range : EUS 0% ~ EUS 10%
▶ PROG RUN
→ Relay is “ON” during TSP minus
setting humidity.
→ Setting range is (EUS 0% ~ EUS 10%)
☞ Status lamp of the running screen and
relay is operated at the same time.
