SAMWONTECH
4th Edition of TEMI880 IM : Jan. 29. 2007 Page 70 / 119
11
HUMI SOAK
SIGNAL
Set relay number for the humidity
Soak signal output.
When Fix running, status lamp of the
running screen is display but relay
output is not occurred.
When Program running, status lamp
of the running screen and relay is
“ON” during Soak time minus setting
time.
13
DRAIN
SIGNAL
Set relay number for the drain water
of the chamber.
POWER ON
PROG STOP (Relay “ON”)
PROG RUN
Temp. SP != DRY LIMIT Range
(Relay “ON”)
Humi. SP is 0.0% (Relay “ON”)
RUN -> STOP “HUMI RUN
SIGNAL” STOP (Relay “ON”)
14
DRAIN
RANGE LOW
Display DRAIN range low of the
ON/OFF operation.
A case DRY LIMIT LOW of
2.12.1.3 Input Display Screen
is changed, it is changed.
Not edit.
15
DRAIN
RANGE HIGH
Display DRAIN range high of the
ON/OFF operation.
A case DRY LIMIT HIGH of
2.12.1.3 Input Display Screen
is changed, it is changed.
Not edit.
16
ERROR
SIGNAL
Set relay number for the error signal
output.
when DI error(DI2 ~ DI8) is occurred,
Relay status is ON” while setting
time.
17
PATTERN
END SIGNAL
Set relay number for the pattern end
signal output.
when program pattern is ended,
Relay status is ON” while setting
time.
18
1st REF.
SIGNAL
Set relay number for the first REF.
signal output.
A case where Inner Signal1(IS1)
output is occurred, Relay status is
“ON” after setting time(second).
19
2nd REF.
SIGNAL
Set relay number for the second
REF.
signal output.
A case where Inner Signal1(IS1)
output is occurred, Relay status is
“ON” after setting time(minute).
A case where setting relay number is duplicated, an occasion what kind of signal output is occurred, relay
is operated.(“OR” Condition)
