BASIC
USER MANUAL
SINUS PENTA
33/97
CAUTION
Always use the correct cable cross-
sections and activate the protective devices provided
for the inverter. Failure to do so will cause the non-
compliance to standard regulations
of the system where the inverter is installed.
NOTE
In modular sizes S65-S9
0, each supply arm shall be protected by a separate fuse (see
table above).
Size
SINUS
PENTA
Model
Rated Output
Current
Rated Input Current
Cable Cross-section
Fitting the Terminal
Tightening
Torque
Motor Cable Cross-
section
A
Adc
mm
2
(AWG or kcmils)
Nm
mm
2
(AWG or kcmils)
S64
0457
720 750 Bus bar
M10: 50
M12: 110
3x150 (3x300kcmils)
0524
800 840 Bus bar
M10: 50
M12: 110
3x185 (3x350kcmils)
0598
900 950 Bus bar
M10: 50
M12: 110
3x240 (3x500kcmils)
0748
1000 1070 Bus bar
M10: 50
M12: 110
3x240 (3x500kcmils)
0831
1200 1190 Bus bar
M10: 50
M12: 110
4x240 (4x500kcmils)
S74
0964
1480 1500 Bus bar
M10: 50
M12: 110
6x150 (6x300kcmils)
1130
1700 1730 Bus bar
M10: 50
M12: 110
6x185 (6x400kcmils)
1296
2100 1980 Bus bar
M10: 50
M12: 110
6x240 (6x500kcmils)
S84
1800
2600 2860 Bus bar
M10: 50
M12: 110
9x240 (9x500kcmils)
2076
3000 3300 Bus bar
M10: 50
M12: 110
9x240 (9x500kcmils)
CAUTION
Always use the correct cable cross-
sections and activate the protective devices installed on
the DC power supply line. Failure to do so will cause the non-
compliance to standard
regulations of the system where the inverter is installed.
