Santerno Sinus Penta - “FOC” Control Algorithm

SINUS PENTA
BASIC
USER MANUAL
46/97
Alarm
Alarm Message
Description
What to do
A099
2nd Sensor
Fault
Fault of fan sensor 2
1. Reset the Penta drive.
2. Contact Elettronica Santerno’s Customer Service.
A100
MDI6 Illegal
Configuration
Function programmed for
MDI6 along with frequency
input A
Check configuration of
MDI6
and setting in
C189
.
A101
MDI8 Illegal
Configuration
Function programmed for
MDI8 along with frequency
input B
A102
REF>20mA
REF Current input (4
÷
20mA
or 0÷20mA) greater than
20mA
1. Check setting of SW1 in the control board.
2. Check the current signal source.
A103
AIN1>20mA
AIN1 Current input
(4÷20mA or 0÷20mA)
greater than 20mA
A104
AIN2>20mA
AIN2 Current input
(4÷20mA or 0÷20mA)
greater than 20mA
A105
PT100 Channel
1 Fault
Hardware address out of
measure range of the drive
1. Check setting of SW1 in ES847 (optional board).
2. Check the current signal source.
A106
PT100 Channel
2 Fault
Hardware address out of
measure range of the drive
A107
PT100 Channel
3 Fault
Hardware address out of
measure range of the drive
A108
PT100 Channel
4 Fault
Hardware address out of
measure range of the drive
A109
Amb.Overtemp.
Ambient overtemperature
1. Open the cabinet and check its conditions. Also check
measure
M062
.
2. Reset the Penta drive.
3. Contact Elettronica Santerno’s Customer Service.
A110 ÷ A127
… Control board failure
1. Reset the Penta drive.
2. Contact Elettronica Santerno’s Customer Service.
Table 1: Alarm Code List.
