BASIC
USER MANUAL
SINUS PENTA
49/97
5.5. State List
Number
State
Description
0 ALARM!!! Alarm tripped
1 START UP The drive is starting up
2 MAINS LOSS Mains loss
3 TUNING The drive is tuning
4 SPEED SEARCHING Searching for motor speed
5 DCB at START DC Braking at start
6 DCB at STOP DC Braking at stop
7 DCB HOLDING DC current for Hold function
8 DCB MANUAL Manual DC Braking
9 LIMIT IN ACCEL. Current/torque limit while accelerating
10 LIMIT IN DECEL. Current/torque limit while decelerating
11 LIMIT IN CONSTANT RPM
Current/torque limit at constant rpm
12 BRAKING Braking module startup or deceleration ramp extension
13 CONSTANT RUN Drive running at speed set point
14 IN ACCELERATION Drive running with motor in acceleration stage
15 IN DECELERATION Drive running with motor in deceleration stage
16 INVERTER OK Drive on Stand-by with no alarms tripped
17 FLUXING Motor fluxing stage
18 MOTOR FLUXED Motor fluxed
19 FIRE MODE RUN Constant rpm in Fire Mode
20 FIRE MODE ACCEL. Acceleration in Fire Mode
21 FIRE MODE DECEL. Deceleration in Fire Mode
22 INVERTER OK*
Drive on Stand-by with no alarms tripped, but void warranty due to alarm trip in
Fire Mode
25 SPARE Board in Spare mode
27 WAIT NO ENABLE Waiting for
ENABLE
command opening
28 WAIT NO START Waiting for
START
command opening
29 PIDOUT min DISAB Drive disabled due to PID output < Min.
30 REF min DISAB. Drive disabled due to REF < Min.
31 IFD WAIT REF.
Drive enabled with IFD control
waiting for reference in order to start
32 IFD WAIT START
Drive enabled with IFD control
waiting for START in order to start
33 DISABLE NO START
When fluxing, the RUN command was not given within the max. time set in
C183. The drive is kept disabled until the RUN command is given.
Table 3: State List
