Sanyo PLC-XE32

-39-
Group/
Item
Item Name Function Initial Range Note
1 Disp Dots 666 0 ~ 4095
2 H Back Porch 142 0 ~ 4095
3 V Back Porch 52 0 ~ 4095
4 Disp Line 448 0 ~ 4095
Group 511 SCART (575i)
0
1 Disp Dots 648 0 ~ 4095
2 H Back Porch 170 0 ~ 4095
3 V Back Porch 68 0 ~ 4095
4 Disp Line 526 0 ~ 4095
Group 520
YCbCr (480i)
0 Total Dots 890 0 ~ 4095
1 Disp Dots 696 0 ~ 4095
2 H Back Porch 150 0 ~ 4095
3 V Back Porch 48 0 ~ 4095
4 Disp Line 458 0 ~ 4095
Group 521
YCbCr (575i)
0 Total Dots 920 0 ~ 4095
1 Disp Dots 704 0 ~ 4095
2 H Back Porch 170 0 ~ 4095
3 V Back Porch 62 0 ~ 4095
4 Disp Line 542 0 ~ 4095
Group 522
YCbCr (480P)
0 Total Dots 858 0 ~ 4095 * Read only
1 Disp Dots 684 0 ~ 4095
2 H Back Porch 138 0 ~ 4095
3 V Back Porch 46 0 ~ 4095
4 Disp Line 460 0 ~ 4095
Group 523
YCbCr (575P)
0 Total Dots 862 0 ~ 4095 * Read only
1 Disp Dots 680 0 ~ 4095
2 H Back Porch 148 0 ~ 4095
3 V Back Porch 60 0 ~ 4095
4 Disp Line 538 0 ~ 4095
Group 524 YCbCr (720P - 60)
0 Total Dots 1650 0 ~ 4095 * Read only
1 Disp Dots 1248 0 ~ 4095
2 H Back Porch 314 0 ~ 4095
3 V Back Porch 34 0 ~ 4095
4 Disp Line 700 0 ~ 4095
Group 525 YCbCr (720P - 50 )
0 Total Dots 1980 0 ~ 4095 * Read only
1 Disp Dots 1248 0 ~ 4095
2 H Back Porch 338 0 ~ 4095
3 V Back Porch 36 0 ~ 4095
4 Disp Line 700 0 ~ 4095
Group 526
YCbCr (1080i - 60)
0 Total Dots 2200 0 ~ 4095 * Read only
1 Disp Dots 1872 0 ~ 4095
2 H Back Porch 258 0 ~ 4095
3 V Back Porch 54 0 ~ 4095
4 Disp Line 1052 0 ~ 4095
Group 527
YCbCr (1080i - 50)
0 Total Dots 2640 0 ~ 4095 * Read only
1 Disp Dots 1870 0 ~ 4095
2 H Back Porch 258 0 ~ 4095
3 V Back Porch 54 0 ~ 4095
4 Disp Line 1052 0 ~ 4095
Group 528
YCbCr (1035i)
0 Total Dots 2200 0 ~ 4095 * Read only
1 Disp Dots 1872 0 ~ 4095
2 H Back Porch 258 0 ~ 4095
3 V Back Porch 88 0 ~ 4095
4 Disp Line 1012 0 ~ 4095
Group 540 RGB Video (480i)
0 Total Dots 960 0 ~ 4095
1 Disp Dots 752 0 ~ 4095
2 H Back Porch 166 0 ~ 4095
3 V Back Porch 48 0 ~ 4095
4 Disp Line 460 0 ~ 4095
5 Clamp 1 0 ~ 255
6 Clamp Width 31 0 ~ 255
