Sanyo PLC-XE32

LE7-XE3200
Electrical Parts List
-58-
Electrical Parts List
Note: Parts order must contain Chassis No., Part No., and Descriptions.
Key No. Part No. Description Key No. Part No. Description
ASSMBLIED BOARDS
! 
655 001 9066 ASSY,PWB,POWER
!
655 001 9042 ASSY,PWB,FILTER
!
655 001 9011 ASSY,PWB,MSW
!
655 002 2608 ASSY,PWB,MAIN
!
655 002 2592 ASSY,PWB,R/C
OUT OF CIRCUIT BOARD
L603 945 003 3835 CORE,FERRITE
L604 645 063 6905 CORE,CLAMP
L605 945 023 4959 CORE,CLAMP
!
LF901 945 078 6472 UNIT,NOISE FILTER
!
LP900 610 330 4564 LAMP,POA-LMP107
!
A901 945 086 0981 UNIT,BALLAST
A901A 910 330 0949 CABLE,BALLAST KR6AC
652 002 3390 CORD,ID-CONNECTOR
!
FN901 945 079 2145 MOTOR,BLW DC 2.76W
!
FN902 945 087 8931 MOTOR,FAN DC 3.12W
!
FN903 945 079 2145 MOTOR,BLW DC 2.76W
!
FN904 945 079 2145 MOTOR,BLW DC 2.76W
SP901 652 002 3055 SPEAKER,8
652 002 4397 SPEAKER,8
!
SW902 945 079 2527 SWITCH,THERMAL(105DEG)
WK8D-28D 652 002 1426 CORD,ID-CONNECTOR
Z690&8S 652 002 0221 CORD,ID-CONNECTOR
ZPE&BDA 610 332 6825 GROUNDING STRAPS
652 002 1969 GROUNDING STRAPS
ZPE&BDB 610 332 6818 GROUNDING STRAPS
652 002 1976 GROUNDING STRAPS
655 001 9066 ASSY,PWB,POWER
TRANSISTOR
Q601 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q602 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q611 305 146 6405 TR 2SK2837
Q621 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q622 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q642 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q643 305 217 6600 TR 2SK3934
Q651 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
INTEGRATED CIRCUIT
IC621 309 523 1413 IC FA5502M
IC631 309 558 4202 IC STR-Z2156A
IC651 309 344 6522 IC UPC1093T-E1
CAPACITOR
C605 303 164 0217 CERAMIC 0.1U Z 25V
C611 303 222 1326 CERAMIC 1000P K 1K
C612 303 222 1326 CERAMIC 1000P K 1K
C613 303 451 4119 MT-POLYEST 1U K 450V
C614 303 451 4119 MT-POLYEST 1U K 450V
C615 304 102 7104 ELECT 120U M 420V
304 106 8800 ELECT 120U M 420V
C616 303 371 8617 MT-POLYEST 0.1U K 450V
303 427 1814 MT-POLYEST 0.1U K 450V
C62A 303 157 3317 CERAMIC 68P J 50V
304 094 9001 CERAMIC 68P J 50V
C62B 303 157 6615 CERAMIC 470P K 50V
304 091 4306 CERAMIC 470P K 50V
C62C 303 374 4210 CERAMIC 0.33U K 10V
C62D 303 164 0217 CERAMIC 0.1U Z 25V
C62E 303 164 0217 CERAMIC 0.1U Z 25V
C62F 303 370 9110 CERAMIC 0.068U K 50V
304 091 5105 CERAMIC 0.068U K 50V
C62I 303 149 9211 CERAMIC 0.01U Z 50V
304 095 4203 CERAMIC 0.01U Z 50V
C62J 303 169 2810 CERAMIC 330P J 50V
304 094 8202 CERAMIC 330P J 50V
C62K 303 323 3615 CERAMIC 0.047U K 50V
C62M 303 164 0217 CERAMIC 0.1U Z 25V
C62R 303 417 9912 CERAMIC 4.7U K 25V
C62T 303 164 0217 CERAMIC 0.1U Z 25V
C631 303 268 7013 TA-SOLID 2.2U M 35V
C633 303 113 3818 CERAMIC 1000P K 50V
304 090 1108 CERAMIC 1000P K 50V
C634 303 247 3319 CERAMIC 330P K 2K
C635 303 167 8616 CERAMIC 220P K 2K
C636 303 070 2619 CERAMIC 0.1U Z 50V
C637 303 157 6813 CERAMIC 680P K 50V
304 091 4900 CERAMIC 680P K 50V
C638 303 182 8110 TA-SOLID 1U M 25V
303 208 1415 TA-SOLID 1U M 25V
303 411 5712 TA-SOLID 1U M 25V
C639 303 410 7618 ELECT 220U M 35V
