Sanyo PLC-XE32 User Manual

Table of Contents
3
Trademarks
Each name of corporations or products in this book is either a registered trademark or a trademark of its
respective corporation.
Features and Design . . . . . . . . . . . . .2
Table of Contents . . . . . . . . . . . . . . . .3
To the Owner. . . . . . . . . . . . . . . . . . . .4
Safety Instructions . . . . . . . . . . . . . . .5
Air Circulation 6
Installing the Projector in Proper
Position 6
Moving the Projector 6
Compliance . . . . . . . . . . . . . . . . . . . . .7
Part Names and Functions . . . . . . . .8
Front 8
Back 8
Bottom 8
Rear Terminal 9
Top Panel 10
Remote Control 11
Remote Control Battery Installation 12
Operating Range 12
Installation. . . . . . . . . . . . . . . . . . . . . .13
Positioning the Projector 13
Adjustable Foot 13
Connecting the AC Power Cord 14
Connecting to a Computer 15
Connecting to Video Equipment 16
Connecting to Component Video and
RGB(Scart) Equipment 17
Basic Operation . . . . . . . . . . . . . . . . .18
Turning On the Projector 18
Turning Off the Projector 19
How to Operate the On-Screen Menu 20
Menu Bar 21
Zoom and Focus Adjustment 22
Keystone Correction 22
Sound Adjustment 23
Remote Control Operation 23
Computer Input . . . . . . . . . . . . . . . . .25
Input Source Selection 25
Computer System Selection 26
Auto PC Adjustment 27
Manual PC Adjustment 28
Image Level Selection 30
Image Level Adjustment 31
Screen Size Adjustment 32
Video Input . . . . . . . . . . . . . . . . . . . . .34
Input Source Selection (Video) 34
Input Source Selection (S-Video,
Component, RGB Scart 21-pin) 35
Video System Selection 36
Image Level Selection 37
Image Level Adjustment 38
Screen Size Adjustment 40
Setting . . . . . . . . . . . . . . . . . . . . . . . . .41
Setting 41
Maintenance and Cleaning . . . . . . . .51
Warning Indicator 51
Cleaning the Air Filters 52
Attaching the Lens Cap 52
Cleaning the Projection Lens 53
Cleaning the Projector Cabinet 53
Lamp Replacement 54
Lamp Replacement Counter 55
Appendix . . . . . . . . . . . . . . . . . . . . . . .56
Troubleshooting 56
Menu Tree 58
Indicators and Projector Condition 60
Compatible Computer Specifications 61
Technical Specifications 62
Optional Parts 63
Configurations of Terminals 64
PIN Code Number Memo 65
Lamp Replacement Label 65
Dimensions 66

Sanyo PLC-XE32 Specifications

General

Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	400:1
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	±20 °
Lamp type	UHP
Lamp power	200 W
Light source type	Lamp
Focus	Manual
Focal length range	22.5 - 27 mm
I/O ports	D-Sub15 S-Video Composite Monitor out D-sub15 Audio out Service Port Mini DIN 8-pin
Dimensions (WxDxH)	330 x 237 x 80 mm
F-number (relative aperture)	1.65
Power consumption (typical)	205 W

Weight and Dimensions

Weight	2900 g
