Sanyo PLC-XE32

Appendix
62
Technical Specifications
Mechanical Information
Projector Type Multi-media Projector
Dimensions (W x H x D) 12.99" x 3.15" x 9.33" (330 mm x 80 mm x 237 mm)
(Not including adjustable foot)
Net Weight 6.4 lbs (2.9 kg)
 FootAdjustment 0˚to10.0˚
Panel Resolution
LCD Panel System 0.6" TFT Active Matrix type, 3 panels
Panel Resolution 1,024 x 768 dots
Number of Pixels 2,359,296 (1,024 x 768 x 3 panels)
Signal Compatibility
Color System PAL, SECAM, NTSC, NTSC4.43, PAL-M, and PAL-N
High Definition TV Signal 480i, 480p, 575i, 575p, 720p, 1035i, and 1080i
Scanning Frequency H-sync. 15 ~ 100 kHz, V-sync. 50 ~ 100 Hz
Optical Information
Projection Image Size (Diagonal) Adjustable from 40" to 300"
Projection Lens F 1.65 ~ 1.81 lens with f 22.5 mm ~ 27 mm with manual zoom and focus
Throw Distance 4.6' - 43.3' (1.4m - 13.2m)
Projection Lamp 200W
Interface
Video Input Jack RCA Type x 1
Audio Input Jacks RCA Type x 2
Computer Input/S-VIDEO Analog RGB (Mini D-sub 15 pin) Terminal x 1
/Component Input Terminal
Monitor Output Terminal Analog RGB (Mini D-sub 15 pin) Terminal x 1
Component/ Computer Audio Input Jack Mini Jack (stereo) x 1
Service Port Connector Mini DIN 8 pin x 1
Audio Output Jack Mini Jack (stereo) x 1 (Variable)
Audio
Internal Audio Amp 1.0 W RMS
Built-in Speaker 1 speaker, ø1.1" (28 mm)
Power
Voltage and Power Consumption AC 100 ~ 120 V (3.2A Max. Ampere), 50/60 Hz (The U.S.A and Canada)
AC 200 ~ 240 V (1.6A Max. Ampere), 50/60 Hz (Continental Europe and The U.K.)
Operating Environment
 OperatingTemperature 41˚F~95˚F(5˚C~35˚C)
 StorageTemperature 14˚F~140˚F(-10˚C~60˚C)
Remote Control
Battery AA or LR6 1.5 V ALKALINE TYPE x 2
 OperatingRange 16.4'(5m)/±30˚
Dimensions 1.9" (W) x 0.87" (H) x 5.7" (D) (49 mm x 22 mm x 145.3 mm)
Net Weight 3.53 oz (100 g) (including batteries)
