Sanyo PLC-XE32 - Configurations of Terminals

64
Terminal: Mini DIN 8-PIN
SERVICE PORT CONNECTOR
COMPUTER IN/S-VIDEO IN/COMPONENT IN/MONITOR OUT TERMINAL (ANALOG)
Terminal : Analog RGB (Mini D-sub 15 pin)
5
1
2
34
10
9 678
15
14
13
11
12
Configurations of Terminals
Red (R/Cr/SC) Input/Output
Ground (Horiz.sync.)
Green (G/Y/SY) Input/Output
-----
Blue (B/Cb) Input/Output
Ground (Red)
Ground (Green)
Ground (Blue)
1
5
2
4
3
6
7
8
5V Power
Horiz. sync. Input/Output (Composite H/V sync.)
Ground (Vert.sync.)
DDC Data
Ground
Vert. sync.
DDC Clock
9
13
10
12
11
14
15
Serial
GND
R X D
-----
-----
RTS/CTS
T X D
GND
4
1
3
2
5
6
7
GND8
