Installation
Connecting to a Computer
UnplugthepowercordsofboththeprojectorandexternalequipmentfromtheACoutletbeforeconnecting
cables.
Cables used for connection
•VGACables(MiniD-sub15pin)*(Onlyonecableissupplied.)
•AudioCables
(*Onecableissupplied;othercablesarenotsuppliedwiththeprojector.)
Note:
 •InputsoundtotheAUDIOINterminalwhenusingtheCOMPUTERIN1/S-VIDEOIN/COMPONENTIN
andtheCOMPUTERIN2/MONITOROUTterminalsasinput.
 •WhentheAUDIOOUTisplugged-in,theprojector'sbuilt-inspeakerisnotavailable.
•Whenthecableisofthelongervariety,itisadvisabletousetheCOMPUTERIN1/S-VIDEOIN/COMPONENTINand
nottheCOMPUTERIN2/MONITOROUT.
ExternalAudioEquipment
Audiocable
(stereo)
Audiocable
(stereo)
AudioOutput
AUDIOIN
AUDIOOUT
(stereo)
AudioInput
MonitorInput
or
MonitorOutput
COMPUTERIN2/
MONITOROUT
VGA
cable
COMPUTERIN1
/S-VIDEOIN
/COMPONENTIN
VGA
cable
Monitor
Output
Thisterminalisswitchable.
Setuptheterminalas
eitherComputerinputor
Monitoroutput.(SeePage
49.)
