Installation

Connecting to Component Video and RGB ( Scart) Equipment

Note:

 •WhentheAUDIOOUTisplugged-in,theprojector'sbuilt-inspeakerisnotavailable.

 •Seepage72fororderingoptionalcables.

Cables used for connection

•AudioCables(MiniPlug:stereo)

•Scart-VGACable

•ComponentCable

•Component-VGACable

(Cablesarenotsuppliedwiththisprojector.)

ExternalAudioEquipment

AUDIOIN

Audiocable

(stereo)

Audiocable

(stereo)

AudioInput

ComponentVideoOutput

(Y,Pb/Cb,Pr/Cr)

AudioOutput

RGBScart

21-pinOutput

Scart-VGA

cable

Component-

VGAcable

AUDIO OUT

(stereo)

Component

cable

COMPUTERIN1/S-VIDEOIN/COMPONENTIN

UnplugthepowercordsofboththeprojectorandexternalequipmentfromtheACoutletbeforeconnecting

cables.
