Part Names and Functions

Rear Terminal

② ③①

④

⑥

⑦

⑤

⑦ AUDIO IN

 Connecttheaudiooutputsignalfromcomputeror

videoequipmenttothisjack(pp.14-16).

⑤ VIDEO IN

 Connectthecompositevideooutputsignaltothis

jack(p.15).

② COMPUTER IN 1 /S-VIDEO IN / COMPONENT IN

 ConnectanalogRGBoutputsignalfroma

computer,S-VIDEOoutputsignalfromvideo

equipment,orRGBscart21-pinvideooutputor

componentvideooutputtothisterminal(pp.14-16).

④ AUDIO OUT (VARIABLE)

 Connectanexternalaudioamplifiertothisjack

(pp.14-16).

 ThisterminaloutputssoundfromAUDIOIN

terminal.

⑥ LAN Connection Terminal

 ConnecttheLANcable(refertotheowner’s

manualof“NetworkSet-upandOperation”).

① CONTROL PORT

 Whentheprojectoriscontrolledbyacomputer,

connecttothisjackwithserialcontrolcable.

③ COMPUTER IN 2 / MONITOR OUT

 –ConnectanalogRGBoutputsignalfroma

 computertothisterminal(p.14).

 –Thisterminalcanbeusedtooutputtheincoming

 analogRGBandComponentsignalfrom

 COMPUTERIN1/S-VIDEOIN/COMPONENTIN

 terminaltotheothermonitor(pp.14,16).
