Sanyo PLC-XR201 - XGA LCD Projector User Manual

35
Computer Input
SelectDigital zoom +.TheOn-ScreenMenudisappearsand
D. zoom +appears.PresstheSELECTbuttontoexpandthe
imagesize.UsethePoint▲▼◄►buttonstopantheimage.
ThePanningfunctioncanworkonlywhentheimageislarger
thanthescreensize.
A projected image can be also expanded by pressing the
D.ZOOM▲ortheSELECTbuttonontheremotecontrol.
ToexittheDigitalzoom+/–mode,pressanybuttonexcept
theD.ZOOM▲▼buttons,SELECTandPointbuttons.
Digital zoom +
SelectDigital zoom –.TheOn-ScreenMenudisappearsand
D. zoom –appears.PresstheSELECTbuttontocompress
imagesize.
Theprojectedimagecanbealsocompressedbypressingthe
D.ZOOM▼ortheSELECTbuttonontheremotecontrol.
Digital zoom –
Toreturn to the previousscreen size, select a screen size
from the Screen SizeAdjustment Menu or select an input
source from the Input Source Selection Menu (see page
27)again, or adjustthescreen sizewiththe D.ZOOM▲▼
buttons.
For zooming in and out the images
Note:
 •Theminimumcompressionratioislimited
dependingontheinputsignal,whenthe
Keystonefunctionisworkingorwhenthe
customisselectedforthescreensize.
 •True,Full,andDigital zoom +/–cannot
beselectedwhen480i,575i,480por
575pisselectedinthePCSystemMenu
(p.28).
 •Digital zoom +/-cannotbeselected
whenFullorTrueisselected.
 •WhenCustomisselected,theDigital
zoom-functionisdisabled.
Remote Control
D.ZOOM + button
POINT buttons
SELECT button
D.ZOOM - button
Adjust the screen scale and position manually with this
function.
PressthePoint
►
buttonatCustomandtheCustomis
displayedonthescreen,youcanusethePoint▲▼buttons
tochoosetheitemyouwanttoadjust.
 Scale H/V.......... AdjusttheHorizontal/Verticalscreen
scale.
 H&V................... WhensettoOn,theaspectratiois
fixed.TheScale Vappearsdimmedand
becomesunavailable.AdjustScale H,
thenthescreenscaleisautomatically
modifiedbasedontheaspectratio.
 Position H/V..... Adjust the Horizontal/Vertical screen
position.
 Common........... Savetheadjustedscaleorpositiontoall
theinputs.PresstheSELECTbuttonat
Commontodisplayaconfirmationbox.
Tosavethescaleorposition,pressthe
SELECTbuttonatYes.WhenCustom
isselected,thesavedscaleorpositionis
used.
 Reset................. Resetthealladjustedvalues.Press
theSELECTbuttonatResettodisplay
aconfirmationbox.Toreset,pressthe
SELECTbuttonatYes.
Custom
Note:
 •Whennosignalisdetected,Normalisset
automatically.
 •TheadjustablerangeforScale H/Vand
Position H/Vislimiteddependingonthe
inputsignal.
