Sanyo PLC-XU300 - Video Input; Screen Size Adjustment

43
This projector has the picture screen resize function, which enables you to customize the image size.
Normal
Screen Size Adjustment
Screen Menu
1
2
Provide the image at the 4:3 normal video aspect ratio.
Custom
Adjust the screen scale and position manually with this
function.
Press the Point 8 button at Custom and the Custom is
displayed on the screen, you can use the Point ed buttons
to choose the item you want to adjust.
Scale H/V .......... Adjust the Horizontal/Vertical screen
scale.
H&V ................... When set to On, the aspect ratio is
fixed. The Scale V appears dimmed and
becomes unavailable. Adjust the Scale
H, then the screen scale is automatically
modified based on the aspect ratio.
Position H/V.....Adjust the Horizontal/Vertical screen
position.
Common ........... Save the adjusted scale or position to all
the inputs. Press the SELECT button at
Common to display a confirmation box.
To save the scale or position, press the
SELECT button at Yes, When Custom is
selected, the saved scale or position is
used.
Reset ................. Reset the all adjusted values. Press
the SELECT button at Reset to display
a confirmation box. To reset, press the
SELECT button at Yes.
✔ Note:
• When no signal is detected,
Normal is set
automatically and the Aspect dialog box
disappears.
• The adjustable range for Scale H/V and
Position H/V is limited depending on the
input signal.
• Wide cannot be operated when 720p,
1035i, or 1080i is selected in the AV
System Menu (p.39).
Wide
Provide the image at the 16:9 wide screen ratio.
Press the MENU button to display the On-Screen
Menu. Use the Point ed buttons to select Screen and
then press the Point 8 or the SELECT button.
Use the Point ed buttons select the desired item and
then press the SELECT button.
Video Input
