Sanyo PLC-XU4000 Service Manual

-51-
Electrical Adjustments
Group/
Item
Item Name Function Initial Range Note
4 Disp Line 1046 0 ~ 4095
Group
547
RGB Video (1080i - 50)
0 Total Dots 2640 0 ~ 4095
1 Disp Dots 1872 0 ~ 4095
2 H Back Porch 260 0 ~ 4095
3 V Back Porch 56 0 ~ 4095
4 Disp Line 1050 0 ~ 4095
Group
548
RGB Video (1035i)
0 Total Dots 2200 0 ~ 4095
1 Disp Dots 1872 0 ~ 4095
2 H Back Porch 260 0 ~ 4095
3 V Back Porch 92 0 ~ 4095
4 Disp Line 1008 0 ~ 4095
Group
981
Color Shading Adj Offset
0 R-Max 128 0 - 255
1 R-Mid1 128 0 - 255
2 R-Mid2 128 0 - 255
3 R-Min 128 0 - 255
4 G-Max 128 0 - 255
5
G-Mid1
128
0 - 255
6 G-Mid2 128 0 - 255
7 G-Min 128 0 - 255
8 B-Max 128 0 - 255
9 B-Mid1 128 0 - 255
10 B-Mid2 128 0 - 255
11
B-Min
128
0 - 255
