-76-
KA2-XU400000
PACKING MATERIALS
610 352 7819 CARTON CASE-KA2AC
610 354 7756 POLY BAG 0440*0480*NC
610 353 7382 CASE ACC-KA2AC
610 352 7857 CUSHION TOP-KA2AC
610 352 7833 CUSHION BTM-KA2AC
ACCESSORIES DIRECTORY
OWNER'S MANUAL
610 353 0895 CD-ROM,OWNERS MANUAL-KA2AC
655 004 1180 SETUP INST-KA2AC
REMOTE CONTROL
645 099 3213 ASSY,REMOCON CXZR
610 344 9944 RC-BATTERY LID-MXAC
AC CORD
! US 645 093 3028 CORD,POWER-2.3MK,US
! EU 645 093 2984 CORD,POWER-2.3MK,EU
! UK 645 093 3004 CORD,POWER-2.3MK,UK
! BRA 645 102 6996 CORD,POWER-2.5MK,BRA
MISCELLANEOUS
610 343 0249 STRAP CAP-KT7AC
610 354 1525 COVER,FLT BOTTOM TTR-KA2AC
610 355 0220 CARRY BAG-KL6A
945 073 4855 CABLE,INTERFACE VGA
645 093 1642 CABLE,INTERFACE VGA
652 002 9552 CABLE,INTERFACE VGA
MECHANICAL PARTS
CABINET PARTS
C01 610 352 7161 COVER LMP-KA2AC
C02 610 353 7276 ASSY CAB FR-KA2AC
C02-1 610 352 9004 DEC LNS-KA2AC
C03 610 353 3407 CAB BTM-KA2AC
C04 610 352 7260 COVER FLT BTM-KA2AC
C05 610 355 4334 CAB TOP SERVICE-KA2AC
C06 610 353 9010 ASSY,ADJ SCREW STEM-KA2AC
C07 610 343 0959 BUTTON CONTROL-KG5AC
C08 610 352 7222 CAP LNS-KA2AC
C09 610 352 7253 COVER FLT SD-KA2AC
C10 610 344 1788 DEC INLAY LED-KF5AC
C11 610 343 0942 DEC INLAY RC-KG5AC
C12 910 325 2477 DEC LEG-PT5EC
C13 610 352 7598 PNL AV-KA2AC
C14 610 343 1017 ADJ_CORE_KG5AC
C15 610 352 7659 STD ADJ BTN-KA2AC
C16 411 001 0300 RING E 5
C17 945 047 8032 BADGE,SANYO*26.2X5.7L26.0
CHASSIS PARTS
M01 610 353 6996 FILTER BOX SD-KA2AC
M02 610 353 7009 FILTER BOX BTM-KA2AC
M03 610 349 0830 BUSH -KJ8AC
M04 610 342 5795 HOLDER INT PBS BTM-KG5AC
M05 610 342 5788 HOLDER INT PBS TOP-KG5AC
M06 610 352 7413 HLD SN-KA2AC
M07 610 352 7420 HOUSE LMP-KA2AC
M08 610 352 7451 HLD FLT DUCT SD-KA2AC
M09 610 352 7499 HLD FLT DUCT BTM-KA2AC
M10 610 352 7482 HLD FN LMP-KA2AC
M11 610 352 9097 HLD PULG-KA2AC
M12 610 343 1314 MTG RELAY OUT-KG5AC
M13 610 352 6713 MTG DUCT PNL TOP-KA2AC
M14 610 352 6720 MTG DUCT PNL BTM-KA2AC
M15 610 352 7536 MTG DUCT LMP T-KA2AC
M16 610 352 7581 MTG SP-KA2AC
M17 610 353 1137 MTG EXH FN-KA2AC
M18 610 353 4442 OPTICAL BASE BTM-KA2AC
M19 610 353 3759 OPTICAL BASE TOP(A)-KG5AC
SCREWS
S01 411 031 9304 SCR BIN 3X8
S02 412 077 9105 SPECIAL SCREW
S03 411 077 8606 SCR TPG FLT 3X8
S04 411 042 0406 SCR PAN 3X8
S05 411 192 5108 SCR PAN+SW+W 2.5X6
S06 412 077 8108 SPECIAL SCREW-2.5X6
S07 312 070 3400 SPECIAL SCREW-3.0X10V
S08 411 191 6304 SCR BIN 2.5X8
S09 411 189 8303 SCR BIN 3X14
OPTICAL PARTS
L01 610 355 2170 ASSY,PNL/PSM-KA2AC
L02-R 610 346 5562 ASSY,POL R IN-KG5AC
L02-G 610 355 2798 ASSY POL G IN-KA2AC
L02-B 610 355 2804 ASSY POL B IN-KA2AC
L03-R 645 099 0571 LENS,RELAY(IN)
L03-G 645 096 4657 LENS,CONDENSER(G)
L03-B 645 096 4657 LENS,CONDENSER(G)
L04 645 096 9218 LENS,PROJECTION
L05 645 099 0564 LENS,CONDENSER(OUT)
L06 645 099 0571 LENS,RELAY(IN)
L07 645 104 0114 LENS,INTEGRATOR(IN)
L08 645 099 0595 LENS,INTEGRATOR(OUT)
L09 645 099 0601 LENS,RELAY(OUT)
L10 645 096 4701 MIRROR(B)
645 101 0247 MIRROR(B)
L11 645 096 4718 MIRROR(R)
645 101 0254 MIRROR(R)
L12 645 104 4631 PRISM(PBS)
L13 645 104 6918 DICHROIC MIRROR (B)
L14 645 104 6901 DICHROIC MIRROR (G)
SERVICE TOOLS
610 343 5596 CD-ROM,PJ SVC TOOL V420
Key No. Part No. Description
Key No. Part No. Description
Note: Parts order must contain Chassis No., Part No., and Descriptions.
Mechanical Parts List
To Next Page
