-74-
Parts Location Diagrams
KA2-XU400000
● In the optical unit
CAUTION:
Part must be placed in specified direction when replacing the optical parts. Please see “Optical Parts
Disassembly” for further instructions.
L13
L14
L03-G
L06
L11
L11
L03-R
L03-B
L10
