- 18 -
Mechanical disassemblies
2
Lamp cover ass'y removal.
1. Loosen the screw-A and remove the Lamp cover ass'y.
A
Lamp cover ass'y
3
Filter removal.
1. Remove the Filter cover and Filter.
Filter cover
Filter
