Sanyo PLV-Z3000 - Lamp Unit Removal

- 25 -
10-1
Lamp unit removal.
1. Loosen the 2 screws-A and remove the Lamp unit.
A
Lamp unit
10-2
Lamp connector removal.
1. Remove the 2 screws(T3X6) and remove the Lamp connector.
Lamp connector
Caution:
When remove the Lamp ballast cable,
be carefull not to damade the cable.
Ballast Cable
Mechanical disassemblies
