Sanyo PLV-Z3000 - Power Unit Removal

- 30 -
13
Power unit removal.
1. Remove the 6 screws-A (M3x6) and remove the Power & Ballast unit.
1. Remove the screw-B (M3x6) and remove the Power & Ballast unit.
A
A
A
A
A
A
B
Power & Ballast unit
Ballast unit
Power unit
Mechanical disassemblies
