- 29 -
12-2
Exhaust Fan (FN901, FN903) removal.
1. Remove the 3 screws-A (T3x8) and remove the Exhaust fan unit.
2. Remove the 8 screws-B (M3x28) and remove the Exhaust fan FN901, FN903.
B
Exhaust fan unit
A
A
A
B
B
B
B
B
B
B
FN901
FN903
Mechanical disassemblies
