Sanyo PLV-Z3000 Service Manual

- 54 -
No. Adjustment Item Initial Value Range Input source / Description
Group: 42 Deinterlacer Setting Setting Progressive Model 2, Parameter
setting
0 Motion Adaptive Weight Value 0/0/0 0 - 255 <KDEINT>
Deinter Setting
-- Group
Group1 :
Composite /
S-Video
Group2 :
Component /
Scart / PC
Group3 : HDMI
1 Angle Interpolation Level 2/2/2 0 - 5 0 : Conservative <====> 5 : Aggressive
2 CUE Low Pass Filter Enable 0/0/0 0 - 1 <CUELPFEN>
Group: 47 Noise Reduction NR ON, Parameter setting
0 Noise Pixel Range 1 0 - 2 <NSRANGEY> / <NSRANGEUV>
1 Noise Region 0 12 0 - 1023 <NSREGIONY0> / <NSREGIONUV0>
2 Noise Region 1 24 0 - 1023 <NSREGIONY1> / <NSREGIONUV1>
3 Noise Region 2 40 0 - 1023 <NSREGIONY2> / <NSREGIONUV2>
4 Noise Gain Level 100 0 - 255 <NSFILTERY**> / <NSFILTERUV**>
Group: 50 2:2pull down setting
0 22Film Mode Sensitivityl 4 1 - 5 Film Detection Sensitivity <FILMSTVT22>
1 22Film Mode Threshold Low 80 0 - 1023 <FILMTHRD22A>
2 22Film Mode Threshold High 120 0 - 1023 <FILMTHRD22B>
3 Video Motion Window Start X 10 0 - 255 <VOFSTARX> Film Mode Detect Range
4 Video Motion Window Stop X 10 0 - 255 <VOFSTOPX> Film Mode Detect Range
5 Video Motion Window Start Y 10 0 - 255 <VOFSTARY> Film Mode Detect Range
6 Video Motion Window Stop Y 10 0 - 255 <VOFSTOPY> Film Mode Detect Range
Group: 51 2:3pull down setting
0 Global Motion Sensitivity 4 1 - 5 Film Detection Sensitivity <FILMSTVT23>
1 Video Motion Sensitivity 4 1 - 5 Film Detection Sensitivity <VOFSTVT>
2 Video Motion Threshold low 120 0 - 1023 <VOFTHRDA>
3 Video Motion Threshold High 180 0 - 1023 <VOFTHRDB>
4 Global Motion 23Film Threshold 100 0 - 1023 <FILMTHRD23>
5 Global Motion Window Start X 10 0 - 255 <GMDST ARX> Film Mode Detect Range
6 Global Motion Window Stop X 10 0 - 255 <GMDST OPX> Film Mode Detect Range
7 Global Motion Window Start Y 10 0 - 255 <GMDST ARY> Film Mode Detect Range
8 Global Motion Window Stop Y 10 0 - 255 <GMDST OPY> Film Mode Detect Range
Group: 52 Scaling Filter
0 Scaling Filter
Setting data Group:
G01 - 2
0 - 37
Group 01 - Composite
G02 - 2 Group 02 - S-Video
G03 - 5 Group 03 - Scart
G04 - 37 Group 04 - PC
G05 - 6 Group 05 - YCbCr/RGB 480i, 575i
G06 - 9 Group 06 - YCbCr/RGB 480p, 575p
G07 - 3 Group 07 - YCbCr/RGB 720p60, 720p50
G08 - 9 Group 08 - YCbCr/RGB 1035i, 1080i60, 1080i50
G09 - 5 Group 09 - YCbCr/RGB 1080p
G10 - 3 Group 10 - HDMI 480i, 575i
G11 - 5 Group 11 - HDMI 480p, 575p
G12 - 37 Group 12 - HDMI 720p60, 720p50
G13 - 9 Group 13 - HDMI 1035i, 1080i60, 1080i50
G14 - 9 Group 14 - HDMI 1080p
1 Difference Scaling Filterng 0 0 - 20 I/P converter Off Setting filter data (G08, G13)
Group: 55 LTI / CTI
0 Video Enhancement Enable 1 0 - 1 VEHEN Effective Composite / S-Video
Electrical Adjustments

Sanyo PLV-Z3000 Specifications

General

Matrix size	0.7 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 146 x 346 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	22.3 - 45.3 mm
Noise level	19 dB
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	3

Weight and Dimensions

Weight	7500 g
