Sanyo PLV-Z3000 Service Manual

- 55 -
No. Adjustment Item Initial Value Range Input source / Description
1 DLTI Gain 3 0 - 15 DLTIGAIN Effective Composite / S-Video
2 DLTI Frequency 2 0 - 3 DLTIFREQ Effective Composite / S-Video
3 Bypass Anti-Alias Filter 0 0 - 1 DTIBYPASSAAL Effective Composite / S-Video
4 Lower DCTI Frequency 1 0 - 1 LOWERDCTIFREQ Effective Composite / S-Video
5 DCTI Gain 4 0 - 15 DCTIGAIN Effective Composite / S-Video
6 DCTI Frequency 0 0 - 3 DCTIFREQ Effective Composite / S-Video
7 Color Shift Limit 3 0 - 3 COLORSHIFTTLMT Effective Composite / S-Video
Group: 60 Sub Image
0 Center Contrast 534/578/534/534/492/492 0 - 1023
Setting Value of Group
Group 1 : Composite (Video), S-Video
Group 2 : Component
Group 3 : Scart
Group 4 : RGB Analog (Computer)
Group 5 : RGB Digital (Digital) : not used
Group 6 : HDMI
Setting Value = (Menu value - Menu center value) x Alpha /
10+Center
Internal range of effective and setting
Contrast [Max] 1023 [Min] 0
Brightness [Max] 1023 [Min] 0
Color [Max] 1023 [Min] 0
Tint [Max] 180 [Min] 0
Sharpness [Max] 57 [Min] 0
WB R/G/B [Max] 1023 [Min] 0
BB R/G/B [Max] 1023 [Min] 0
1 Center Brightness 512/512/496/496/512/512 0 - 1023
2 Center Color 512/512/512/512/512/524 0 - 1023
3 Center Tint 90/90/90/90/90/90 0 - 180
4 Center Sharpness 16/16/16/16/16/16 16
5 Center WB Red 512/512/512/512/512/512 0 - 1023
6 Center WB Green 512/512/512/512/512/512 0 - 1023
7 Center WB Blue 512/512/512/512/512/512 0 - 1023
8 Center BB Red 512/512/512/512/512/512 0 - 1023
9 Center BB Green 512/512/512/512/512/512 0 - 1023
10 Center BB Blue 512/512/512/512/512/512 0 - 1023
11 Alpha Contrast 60/60/60/60/60/60 0 - 1000
12 Alpha Brightness 90/90/90/90/90/90 0 - 1000
13 Alpha Color 140/140/140/140/140/140 0 - 1000
14 Alpha Tint 10/10/10/10/10/10 0 - 1000
15 Alpha Sharpness 10/10/10/10/10/10 0 - 1000
16 Alpha WB Red 40/40/40/40/40/40 0 - 1000
17 Alpha WB Green 40/40/40/40/40/40 0 - 1000
18 Alpha WB Blue 40/40/40/40/40/40 0 - 1000
19 Alpha BB Red 20/20/20/20/20/20 0 - 1000
20 Alpha BB Green 20/20/20/20/20/20 0 - 1000
21 Alpha BB Blue 20/20/20/20/20/20 0 - 1000
Group: 80 FPGA
0 Software version - Read Only
1 Hardware version - - Read Only
2 Horizontal total - - Read Only
3 Vertical total - - Read Only
4 Horizontal resolution - - Read Only
5 Vertical resolution - - Read Only
6 Color manager enable 0 0 - 1 Gamma adjustment algorithm o : Disable 1 : enable
7 Y range 8 0 - 32
8 Hue range 15 0 - 30
9 Gain range 30 0 - 50
10 Min slope 3 0 - 10
11 Max slope 18 10 - 30
12 Convergence 3 1 - 5
13 Same hue 3 1 - 10
14 UV normaliz 5 0 - 64
15 Min Y 0 0 - 127
16 Max Y 255 128 - 255
17 Area big change 67 0 - 4095
18 Area small change 67 0 - 4095
19 Area change sense 150 0 - 4095
20 Same Y 24 0 - 63
21 Conv Y 64 0 - 127
Electrical Adjustments

Sanyo PLV-Z3000 Specifications

General

Matrix size	0.7 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 146 x 346 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	22.3 - 45.3 mm
Noise level	19 dB
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	3

Weight and Dimensions

Weight	7500 g
