- 56 -
No. Adjustment Item Initial Value Range Input source / Description
22 WB Limit 0 4 0 - 255
23 WB Limit 1 4 0 - 255
24 WB Limit 2 6 0 - 255
25 WB Limit 3 7 0 - 255
26 WB Limit 4 9 0 - 255
27 WB Limit 8 16 0 - 255
28 UV DLT 3 0 - 31
29 UV Gain 1030 0 - 2047
30 UV Shift 6180 0 - 32767
31 WB Limit Out 16 0 - 255
32 WB Limit In 8 0 - 255
33 Limit mode 3 0 - 7 LIMIT_MODE register setting
34 Reset mode 2 0 - 5 RESET_MODE register setting
Group: 100 LCD Panel (EP7130) Factory Adjustment Value
0 ColshdLebel_R 374 0 - 1023 R_Min
1 421 0 - 1023 R_Mid6
2 451 0 - 1023 R_Mid5
3 482 0 - 1023 R_Mid4
4 562 0 - 1023 R_Mid3
5 620 0 - 1023 R_Mid2
6 702 0 - 1023 R_Mid1
7 764 0 - 1023 R_Max
8 ColshdLebel_G 362 0 - 1023 G_Min
9 407 0 - 1023 G_Mid6
10 434 0 - 1023 G_Mid5
11 460 0 - 1023 G_Mid4
12 523 0 - 1023 G_Mid3
13 565 0 - 1023 G_Mid2
14 627 0 - 1023 G_Mid1
15 676 0 - 1023 G_Max
16 ColshdLebel_B 348 0 - 1023 B_Min
17 387 0 - 1023 B_Mid6
18 409 0 - 1023 B_Mid5
19 430 0 - 1023 B_Mid4
20 474 0 - 1023 B_Mid3
21 500 0 - 1023 B_Mid2
22 536 0 - 1023 B_Mid1
23 564 0 - 1023 B_Max
Group: 101 LCD Panel (EP7130) Service
0 DXOut_R 18 0 - 1023
1 DXOut_G 18 0 - 1023
2 DXOut_B 18 0 - 1023
3 H_Change_Pos 0 0 - 256
4 DYOut_R 32 0 - 511
5 DYOut_G 32 0 - 511
6 DYOut_B 32 0 - 511
7 DXOutPos 0 0 - 1
8 SH_Pos 273 0 - 4095
9 SH_Pos_R 1 0 - 12 Sample & Hold Signal Posishon Control (R)
10 SH_Pos_G 1 0 - 12 Sample & Hold Signal Posishon Control (G)
11 SH_Pos_B 1 0 - 12 Sample & Hold Signal Posishon Control (B
12 NRG_Pos 53 0 - 1023
13 NRG_Widht 13 0 - 1023
Electrical Adjustments
